Deploying your Stack (“Development for Dummies”)

This document goes through the deployment of a full developer stack. It will show how to:

• Set up the first instance of the developer stack

• Clone the database and media from the production stack into your developer stack

• Set GitHub Actions up to automatically push to your stack when changes are made to the master branch, using forks of the fragalysis repositories

Getting started

Forking from GitHub

The fist step is to ensure that you have forked the master branch of each component of the fragalysis stack:

1. xchem/fragalysis-backend

2. xchem/fragalysis-frontend

3. xchem/fragalysis-stack

Old forks should have the current version of master put in - changes to the stack include changes to how CI/CD works, so it is important that all forks are brought up-to-date with the master branch of the XChem repositories

Creating your stack

The stack image for your development environment can be accessed at https://awx-xchem.informaticsmatters.org/#/login [1].

Once you are logged in, you can find the templates for the jobs you can run under Templates on the left-hand side of the page. For standard developers, there are two kinds of jobs:

• Common […] - these jobs are for duplicating the database and media components into your own stack

• User […] - these jobs are for deploying or wiping the stack

If someone hasn’t already run the first stack job for you, here’s how to do it:

1. Run the User (<name>) Developer Fragalysis Stack job

   • NB: the URL for your stack is emitted in the output of this job

   • NB: you must be logged in as your own user to create your own stack. You CANNOT run any other user’s template

If you need a copy of the production/staging stack’s data (and media): -

1. Run the Common Database Replicator (One-Time) job if you

   • NB: you must be logged in as your own user for this to populate your stack You can only replicate to your own stack.

2. Run the Common Media Replicator (One-Time) job

   • NB: you must be logged in as your own user for this to populate your stack You can only replicate to your own stack.

Each job can be launched by clicking on the rocket icon next to the template, this will open the job template, and allow you to launch it. For these first steps, it is fine to run the jobs without changing any parameters.

When the jobs are finished, navigate to the URL spat out by the job in step 1 above. You should now have a copy of the stack that is created from the xchem/master branches.

Wiping your stack

A playbook exists to wipe (erase) a stack. This playbook deletes the stack’s Pods (including th database), and the database and (optionally) the media volumes. This ensures any future re-deployment of the stack will be “reset” (empty).

To wipe a stack: -

1. Run the User (<name>) Developer Fragalysis Stack [WIPE] job

   • NB: you must be logged in as your own user for this to erase your stack. You cannot erase someone else’s stack.

Once a stack is wiped you will need to run the corresponding User job to deploy the (now clean) stack.

Keycloak

Stack developers are likely to need access to a developer-specific Client ID configured on the keycloak server on the Development cluster.

Use an existing client ID for reference but each will need its own ID and. For example, an ID called fragalysis-{developer}-default-xchem-dev with: -

• Client Protocol openid-connect

• Access Type confidential

• Standard FLow Enabled

• Direct Access Grants Enabled

• Service Accounts Enabled

• Authorization Enabled

• Valid Redirect URIs that contain: - - https://fragalysis-{developer}-default.xchem-dev.diamond.ac.uk/oidc/callback/ - http://fragalysis-{developer}-default.xchem-dev.diamond.ac.uk/viewer/react/landing - http://fragalysis-{developer}-default.xchem-dev.diamond.ac.uk/oidc/callback/

Provide the developer with the Client ID and its Secret. These are then used to provide values to the stack Pod’s environment through the following AWX Job Template variables for the corresponding user stack: -

• stack_oidc_rp_client_id

• stack_oidc_rp_client_secret

Setting up GitHub Actions for CI/CD

In this deployment, we use GitHub Actions to run our CI/CD process.

Intro to how the CI/CD works

This is a cumbersome but worthwhile step. First of all, you should decide which repositories you want to work on and fork them.

Once forked, you can configure GitHub Actions in your account to automatically trigger builds when you push changes, and automatically deploy your stack images from your own dockerhub account. The AWX job that we set up earlier looks for the dockerhub stack image that you build and push, based on variables that define the image ownership (namespace). By default the AWX template job will assume the image _namespace_ is xchem and the image tag latest, so the default image reference for the Fragalysis Stack is xchem/fragalysis-stack:latest.

You control each repository’s CI/CD process using Secrets that you create in your fork of the corresponding repository. The xchem repositories have a set that builds the Stack correctly for them.

The quickest way to see what build variables are available, and what they do, is to look at the repository’s .github/workflows/build-main.yaml file. The comments at the top of the file describes its variables in detail.

Here, I’ll list all the variables that can be added for each deployment. The backend, frontend and loader configurations are optional, depending on what repository you want to work on. However, you should configure your stack variables if you want to automatically push to your live deployment when you push changes to a branch (I’d suggest setting this up just for master)

Adding (Secrets) to a GitHub repository

1. Log in to GitGub

2. Navigate to the repository fork you’ve made

3. Click on Settings

4. Click on Secrets in the left-hand panel

5. Add the relevant secrets (described below) as a New repository secret

Fragalysis GitHub secrets

Backend variables (secrets)

Variables related to images (Dockerhub):

• DOCKERHUB_USERNAME - Dockerhub username to allow you to push

• DOCKERHUB_TOKEN - Dockerhub user access token to allow you to push

• BE_NAMESPACE - the Dockerhub namespace you want to push to (e.g. reskyner if you’re pushing to reskyner/fragalysis-backend)

If you set TRIGGER_DOWNSTREAM (to yes) a successful build of the backend will trigger a build of the corresponding stack, using the following optional variables: -

• FE_NAMESPACE - the namespace of the frontend you’ll want in your Stack image (e.g. reskyner if you’re expecting to use reskyner/fragalysis-frontend)

• FE_BRANCH - the frontend repository branch you’ll want in your Stack image (e.g. main if you’re expecting to use main)

• STACK_NAMESPACE - the namespace of the stack you expect to be built (e.g. reskyner if you’re expecting to use reskyner/fragalysis-stack)

• STACK_BRANCH - the stack branch you want to build (e.g. main if you’re expecting to use main)

You will need to define the following, a user and GitHub personal access token that can trigger the Stack build: -

Variables related to GitHub fragalysis-stack repo: -

• STACK_USER - GitHub user for stack

• STACK_USER_TOKEN - GitHub user token

Optional (have defaults): -

• BE_IMAGE_TAG (default = latest) (dockerhub if not latest)

Frontend variables (secrets)

Variables related to automated build:

• TRIGGER_DOWNSTREAM - yes to trigger build of the stack

Variables related to GitHub fragalysis-stack repo:

• STACK_USER - GitHub user for stack

• STACK_USER_TOKEN - GitHub user token

Variables related to images (Dockerhub):

• BE_NAMESPACE - docker namespace for the backend (default xchem)

• BE_IMAGE_TAG - docker tag for the backend (default latest)

Variables related to frontend GitHub repo:

• FE_NAMESPACE – front-end namespace to use in the stack

• FE_BRANCH - front-end branch

Variables related to stack GitHub repo:

• STACK_NAMESPACE – stack namespace to trigger

• STACK_BRANCH - stack branch to trigger

Stack variables (Mandatory for automated builds)

Variables related to stack image - the one your stack will use (Dockerhub):

• DOCKERHUB_USERNAME - dockerhub username to allow push

• DOCKERHUB_TOKEN - dockerhub password to allow push

• STACK_NAMESPACE - the Dockerhub namespace you want to push to (e.g. reskyner if you’re pushing to reskyner/fragalysis-stack)

Variables setting which back-end image to use (optional - will default to xchem/master):

• BE_NAMESPACE - the Dockerhub namespace you want to use (e.g. reskyner if you’re using reskyner/fragalysis-backend)

• BE_IMAGE_TAG - docker image tag (optional, will default to :latest)

Recommended set-up for front-end developers

Fork the xchem/fragalysis-frontend repo from GitHub

Fork the xchem/fragalysis-stack repo from GitHub

Setup the following GutHub repository secrets for the front-end GitHub Actions: -

• Secrets related to triggering the stack:

  TRIGGER_DOWNSTREAM = yes
  STACK_USER
  STACK_USER_TOKEN


• Variables related to frontend GitHub repo:

  FE_NAMESPACE = <your GitHub account name here>
  FE_BRANCH = master


• Variables related to stack GitHub repo (that you’ve forked):

  STACK_NAMESPACE = <your GitHub account name here>
  STACK_BRANCH = master


Setup the following GitHub secrets for the stack you’ve forked:

• Variables related to stack image - the one your stack will use (Dockerhub):

  DOCKERHUB_USERNAME
  DOCKERHUB_TOKEN


Now that you’ve done this, every time you push a change from a branch into master in your frontend fork:

• The tests for the front-end will run as a GitHub Action

• If the tests pass, the stack CI/CD will be triggered

• When the stack-job completes, an image of that stack will be pushed to your Dockerhub repo that you can use in your AWX Job Template

Alternative deployment strategy - Developing locally

On the xchem/fragalysis-backend and xchem/fragalysis-frontend repositories, there are instructions on how to set up a local development environment using Docker in the README.md files in the root of the respective repository.

Part of the process of using this local environment includes building the backend and/or frontend images, and using them locally, and then using those images to build a stack image Because the stack image is all that is needed to push a new version into a live stack, the following process can be used to use those locally built images to push to your stack on AWX:

1. log in to docker:

   $ docker login --username=<your hub username> --password=<your password>


2. Build your image by executing the docker build command. DOCKER_ACC is the name of your account, DOCKER_REPO is your image name and IMG_TAG is your tag:

   $ docker build -t $DOCKER_ACC/$DOCKER_REPO:$IMG_TAG .


   e.g. docker build -t reskyner/fragalysis-stack:latest . is the command for rachael to build her stack image, ready to push do dockerhub.

3. Now, you can push this image to your hub by executing the docker push command:

   $ sudo docker push $DOCKER_ACC/$DOCKER_REPO:$IMG_TAG


   This will push the image up to dockerhub. The only image you need to push is the stack image, as this is the image used by AWX to build your stack.

4. Go to AWX, and navigate to your User (<name>) Developer Fragalysis Stack (Version Change) job template

5. In the EXTRA VARIABLES section, change stack_image: xchem/fragalysis-stack to point to your image (e.g. reskyner/fragalysis-stack)

6. Save and launch the job

7. Navigate to the stack to see the changes from your local dev environment live in the wild!

Footnotes

[1]

Rachael (rachael.skyner@diamond.ac.uk) will give you your username and password to log in
